Hilux Bullbar

Brand / Type: Rockarmor GT 3 Hoop Bull Bar

Suits / Fits: 08/2020 - Current Model Toyota Hilux / Fits Facelift Hilux



Features:

• 55mm Steel Tube
• ADR Approved: YES
• Winch Compatible: Yes (up to 12,000lbs Winch)
• Led Fog Lights & Indicators Included with Bull Bar
• Rated Recovery Points Included with Bull Bar
• Bash Plate included with Bull Bar
• Fitting Instructions Video & PDF Available
• Slotted Antenna Points found on top Tube
• Full Bumper Replacement - No need to keep factory Bumper
• High Approach Angles, great for off road clearance
• Australian Designed & Tested
• Radar Compatible
• High Lift Jack Compatible
• Parking Sensor Compatible
• Colour: Textured Black Powder Coat Finish

Warranty

12 months Manufactures Warranty from Rockarmor

Easy D.I.Y Fitting

We include both PDF & Video instructions to help make your DIY fitting at home much easier

Fits the following Toyota Hilux Models:

Years: 08/2020+ Also fits

SR & SR5 DUAL CAB & SINGLE CAB



Bull Bar Package Contents Include:

• 1 X ROCKARMOR GT BULL BAR
• 1 X WINCH CRADLE
• 2 X RATED RECOVERY POINTS (DRIVERS SIDE & PASSENGER SIDE)
• 1 X CENTRE BASH PLATE
• 2 X WING STONE GUARD PLATES
• 2 X LED FOG LIGHTS (WITH DRL)
• 2 X LED INDICATORS (WITH DRL)
• 1 X FITTING KIT (BOLTS, NUTS, WASHERS)

Rockarmour GT V2 Hoop Bull Bar - Toyota Hilux 08/2020+

Suits:  Toyota SR Hilux / Also Compatible with SR5

Does not fit following models: Workmate / Rouge / Rocco



REVAMPED ROCKARMOR GT HILUX BULL BAR

We have recently revamped our Hilux GT Bull Bar, enhancing its appearance by eliminating the bumper spots which made way for a centred LED light bar mount. Additionally, we have removed 100mm from the front top, passenger, and driver's side wings, resulting in a more captivating and formidable bull bar for your new Toyota Hilux



Features & Specifications:



• Built in 5 Tonne Rated Recovery Points
• 52 mm Top cross tube for maximum frontal protection
• Durable 2.8mm High Quality steel construction for maximum protection
• Designed for high approach angles
• Built in LED Light bar Mount
• Built in LED FOG lights & LED Indicator, compatible with factory controls
• Extended centre Bash Plate Included
• ADR Complied Air bag compatible mounting system
• Factory Sensor & Front Camera Compatible
• Replacement Windscreen Washer bottle included
• Side under Protection panels Included
• Twin Slotted Antenna Mounts located on top Cross Tube
• Twin Hi-Lift jack points
• Accomodation for Electric Winch up to 12,000 pound
• Lazer cut Holes to accommodate for driving lights
• Shot blasted, Chemical Washed
• Finished off in a high quality black powder coat finish



Designed locally in Australia, Rockarmor's all new GT Bull Bar series comes with a modern look, suited towards today's late model vehicles, that require maximum protection,

while complementing your vehicle's factory modern aesthetics.

As well as offering your Hilux with maximum frontal protection, The Rockarmor GT bull bar has been designed to improve your Hilux's off road experience with a number of features that include, higher approach angles, Built in Rated Recovery points for off road recoveries, and provisions for vital accessories that includes, electric winches, driving lights & uhf communication.

The full bumper replacement Steel bull bar allows you to fit the GT bull bar to your Hilux with out having to cutting the factory bumper.

The Rockarmor GT Bull Bar, has been engineered to be compatible with your vehicle safety features which include the front safety camera & bumper sensors.

The bull bar is finished in a highly durable black powder coat finish, Optional colour matching is available through your local Rockarmor Distributor.





FITTING INSTRUCTIONS: (V1 GT Bullbar in the video)

Same instructions apply to the V2 GT Hilux Bull Bar







TOYOTA HILUX SR & SR5 GT BULL BAR (08/2020 - CURRENT)

Full Bumper Replacement / Winch Compatible / ADR Complied / Built in Rated Recovery Points

Upgrading your vehicle's suspension to withstand the additional weight of 60-100kgs from the bull bar and optional winch is indeed important for several reasons:

1. Weight capacity: Factory suspensions are designed to handle specific weights, and adding the extra weight of a bull bar and winch can exceed the suspension's limits, leading to premature wear and potential failure.

2. Sagging and bumpy ride: Without proper suspension upgrades, the front suspension may sag under the added weight, causing the vehicle to ride unevenly and uncomfortably. This can lead to a less stable driving experience and may affect handling and control.

3. Risk of damage: A sagging suspension can put additional stress on various vehicle components, such as tires, springs, and shock absorbers. Over time, this can lead to further damage and increased maintenance costs.

To ensure the proper fitment of the bull bar and minimise potential issues, it's essential to leave a minimum 10-15mm gap between the bull bar and the body of the vehicle. This gap allows for independent movement between the chassis and body, reducing the risk of stress and damage to the vehicle's structure.

It's always best to consult with a qualified mechanic or automotive specialist who can assess your vehicle's suspension system, recommend suitable upgrades, and install the bull bar properly while maintaining the necessary clearance. This way, you can ensure the safety and performance of your vehicle when carrying additional loads.



Bull Bar Warranty:

The bull bar is provided with a 12months Manufacturers Warranty from Rockarmor 4x4
